Completions Hydraulics Handbook (Repost)

This handbook is designed to be an educational as well as a reference handbook.

This version of the “Hydraulics Calculation Handbook” uses American units of measurements only.

Table of Contents
Chapter 1 AREA. VOLUME and CAPACITY
Area
Volume
Capacity
Displacement of Fluids
Chapter 2 PRESSURE
Applied Pressure
Hydrostatic Pressure
Fluid Gradients of Mixtures
Slurry Gradients
Gas Gradients
Differential Pressure
Chapter 3 FORCE
Force Due To Pressure
Forces Due To Pressure Differentials
String Weight and Buoyancy
Chapter 4 HYDRAULIC FORCES and HOOK-LOADS
Single Grip Retrievable Packers
Hydraulic Forces and Single Grip Packers
Hydraulic Forces and Double Grip Packers
Hook Loads
Tubing O.D. Smaller Than Packer Bore
Tubing O.D. and I D. Larger than Packer Seal Bore
Tubing O.D. Larger than Packer Seal Bore and Tubing I D. Smaller Than Packer Seal Bore
General Hook Load Calculations for Unplugged Tubing
Seal Assemblies
Plugged Tubing
General Hook Load Calculations for Plugged Tubing
Tapered Tubing Strings
Chapter 5 FORCE and LENGTH CHANGES
Force and Length Changes
Piston Effect
Ballooning
Bulkling
Temperature Effects
Applied Forces
The Total Effect
Chapter 6 TUBING STRING
Tubing String
Tubing Classification
Chapter 7 TUBING ANCHORS
Tubing Anchor Calculation for Rod Pumped Wells
Mechanical Anchors Used in Rod Pumped Wells
Glossary
Appendix
Tubing Data
Casing Data
Annular Volumes
Fluid Gradients
Pressure and Temperature
Tubing Stretch
Tubing Anchors
Miscellaneous
