Camnetics GearTeqSE for Solid Edge 2012.104.0.415
Camnetics GearTeqSE for Solid Edge 2012.104.0.415 | 12.2 Mb
GearTeq is a gear component design add-in. Create standard and non standard gear components.
GearTeq is a gear component design add-in. Create standard and non standard gear components.
Some of GearTeq's enhanced features:
- Work on Multiple types of components in the same assembly
- See any changes to the geometry instantly on the display window
- Multiple gears created as a single SolidWorks part
- Internal splines can be used as a bore on all components
- Modifying CAD parts created by GearTeq is very easy
- Automatically create assemblies in SolidWorks with proper mating
- Ten standard planetary gear systems are available with a few clicks
- High ratio cycloid set (a single eccentrically mounted planet and a fixed internal gear)
- On screen animations to help you visualize the working gears
- Warnings when GearTeq detects something in your design that may not be proper
- 3D wire frame with some surface shading
- Create XY outputs of the involute points in Excel and text files
- Create data sheets using Excel or text files
- A description of each parameter is in the lower section of the property grid
- Involute profile modification using linear or parabolic deviation for spur and helical gears
- Automatic balance of addendum modification for spur and helical gears
- Create additional tooth profiles that take into consideration the shrinkage of molded plastic gear teeth
- Deviation chart for DIN splines, hub space width/shaft tooth thickness fit
- An easy to use sizing for standard spur gears
- Programmed on a platform that will allow greater enhancements in the future
Home Page - http://www.camnetics.com/
