Bim Revit Structure: Steel Project + Details & Shop Drawings

Steel Project in Revit 2026: Columns, Beams, Base Plates, Connections, Views & Sheets & BIM Navisworks Clash Detection

What you'll learn

Revit 2026 steel modeling with real-world project flow

Set up structural plans with DWG, levels, and grids

Model columns, beams, base plates & retaining walls

Add custom steel connections, splices, and ramps

Create sharp construction docs and detailing views

Export to Navisworks for clash checks and reports

Organize views & sheets for clean construction sets

Align elements across levels with precision

Enhance 3D visuals for stakeholder reviews

Control view templates and annotations easily

Requirements

Basic knowledge of Autodesk Revit

Description

Learn to model, detail, and document steel structures in Revit 2026 through a complete, real-world BIM workflow.1. How to model and detail steel structures in Revit 2026 using real project workflows?2. What are the best practices for creating custom connections, splices, and base plates?3. How to set up a Revit project environment efficiently for steel structure modeling?Elevate your Revit expertise with a professional, project-based course focused on steel structures. From setting up models and importing DWGs to advanced detailing, clash detection, and construction-ready documentation—gain the skills to handle real-world BIM projects with confidence.Headlines:Revit 2026 steel modeling with real-world project flowSet up structural plans with DWG, levels, and gridsModel columns, beams, base plates & retaining wallsAdd custom steel connections, splices, and rampsCreate sharp construction docs and detailing viewsExport to Navisworks for clash checks and reportsOrganize views & sheets for clean construction setsChoose this course to gain hands-on experience with real-world steel structure projects, master advanced Revit 2026 tools, and build the confidence to deliver professional BIM documentation from start to finish. It’s practical, industry-focused, and designed to make you job-ready.You’re progressing well. If you have any questions, feel free to ask—you have my full support.

Overview

Section 1: Introduction

Lecture 1 Fundamentals of Steel Structure Modeling in Revit

Lecture 2 Core Principles of Steel Connections in Revit

Lecture 3 Project Overview, Initial Settings, and Level Creation

Lecture 4 Importing DWG Files and Creating Project Grids in Revit

Lecture 5 Importing DWG Column Sections and Configuring Initial Parameters

Lecture 6 Creating a Professional BOX Column Family for the Project

Lecture 7 Complete Technical Modeling of Structural Columns with Revit

Lecture 8 Creating Beam Families (IPE, J, PG) with Pro Tips in Revit

Lecture 9 Modeling Basement Level Beams with Advanced Techniques

Lecture 10 Adding Main Structural Steel Connections on Basement Level

Lecture 11 Creating Custom Steel Connections for the Project

Lecture 12 Drawing and Configuring the Project Foundation in Revit

Civil Engineers,Stuctural Engineers,BIM Modelers,Architects,Revit Users,BIM Coordinators,BIM Managers,3D Modelers,BIM Drafters,Autocad Drafters,Construction Managers,Project Managers,Revit Architecture Users,Detail Drafters,Shop Drawing Users
